Tipo
Dimensões (mm)
Teeth Geometry
GRADE
D d H L
FMD-H-PM-4EL-D03.00 03.0 13.0 3 75 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D03.0S 03.0 13.0 4 75 4 FIGURE 1 RWK44
FMD-H-PM-4EL-D03.0T 03.0 13.0 6 75 4 FIGURE 1 RWK44
FMD-H-PM-4EL-D04.00 04.0 15.0 4 75 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D04.0T 04.0 15.0 6 75 4 FIGURE 1 RWK44
FMD-H-PM-4EL-D05.00 05.0 20.0 5 75 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D05.0T 05.0 20.0 6 75 4 FIGURE 1 RWK44
FMD-H-PM-4EL-D06.00 06.0 20.0 6 75 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D08.00 08.0 25.0 8 100 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D10.00 10.0 30.0 10 100 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D12.00 12.0 35.0 12 100 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D14.00 14.0 40.0 14 100 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D16.00 16.0 50.0 16 150 4 FIGURE 2 RWK44
FMD-H-PM-4EL-D20.00 20.0 55.0 20 150 4 FIGURE 2 RWK44
